class Game:
def __init__(self, payoffs: torch.Tensor | nn.Parameter, actions: List[List[str]], name=None):
self.num_players = payoffs.shape[0]
self.payoffs = payoffs
self.actions = actions
self.name = name or "Unnamed Game"
self._size = payoffs.shape
@property
def size(self):
return self._size
def payoff(self, action_indices):
return self.payoffs[(slice(None),) + tuple(action_indices)]
def to(self, device):
return Game(self.payoffs.to(device), self.actions, self.name)
def clone(self):
if isinstance(self.payoffs, nn.Parameter):
return Game(nn.Parameter(self.payoffs.detach().clone()), self.actions, self.name)
else:
return Game(self.payoffs.detach().clone(), self.actions, self.name)
def __repr__(self):
learnable = isinstance(self.payoffs, nn.Parameter) and self.payoffs.requires_grad
return f'<Game "{self.name}" size={self._size} learnable={learnable}>'
Introduction
Given a set of agents playing a game, how do we determine their optimal strategic behavior?
In the last post we looked at ways to differentiably identify equivalence classes of games. In this short post, we’ll use gradient descent to identify the Nash equilibria for some simple games.
Background
Identifying Nash equilibria (or other strategic behavior) is difficult in general1.
At some point I will get into traditional algorithms like support enumeration or Lemke-Howson for finding equilibria. However, for the purposes of this post I will investigate composing parametrized agents using games, and learning the Nash equilibria via gradient descent.
Implementation
We’ll build some simple classes to implement this experiment.
Game
First, we need some game representation.
Here, the payoffs are either raw tensors or learnable (if you pass in parameters). Parametrized payoffs are useful for tasks like optimizing welfare, mechanism design, inverse RL, etc.
Agent
Next, we need agents that can play the game.
class Agent:
def __init__(self, policy, name: str):
self.name = name
self.policy = policy
def act(self, actions: List[str]):
probs = self.policy(actions)
dist = torch.distributions.Categorical(probs)
action_idx = dist.sample().item()
return action_idx, actions[action_idx]An agent just samples from the policy distribution and takes an action.
Policies
What kind of policies might the agent have?
Abstract
We’ll start with the abstraction. We have a _run_once helper to prevent double initializing a policy.
def _run_once(method):
attr_flag = f"__{method.__name__}_has_run"
@functools.wraps(method)
def wrapper(self, *args, **kwargs):
if getattr(self, attr_flag, False):
return
setattr(self, attr_flag, True)
return method(self, *args, **kwargs)
return wrapperclass Policy(ABC):
def __init__(self):
pass
def __init_subclass__(cls, **kwargs):
super().__init_subclass__(**kwargs)
# If the subclass overrides 'initialize', wrap it exactly once.
if "initialize" in cls.__dict__:
cls.initialize = _run_once(cls.__dict__["initialize"])
@abstractmethod
def initialize(self, actions: List[str]) -> None:
pass
@abstractmethod
def forward(self, actions: List[str]) -> torch.Tensor:
pass
def __call__(self, actions: List[str]) -> torch.Tensor:
if hasattr(self, "initialize"):
self.initialize(actions)
return super().__call__(actions) Logits
Our first policy is just a logits policy.
class LogitsPolicy(Policy, nn.Module):
def __init__(self, initialization='uniform'):
Policy.__init__(self)
nn.Module.__init__(self)
self.initialization = initialization
self.logits = None
def initialize(self, actions: List[str]) -> None:
num_actions = len(actions)
if self.initialization == 'uniform':
self.logits = nn.Parameter(torch.zeros(num_actions))
elif self.initialization == 'random':
self.logits = nn.Parameter(torch.rand(num_actions))
def forward(self, actions: List[str]) -> torch.Tensor:
return torch.softmax(self.logits, dim=0)We’ll hold off on other policies until later posts.
Arena
Let’s compose Agents and Games in “Arena” objects. This is just to cleanly separate Agents from Games.
class Arena:
def __init__(self, game: Game, agents: List[Agent]):
assert len(agents) == game.num_players
self.game = game
self.agents = agents
for i, agent in enumerate(self.agents):
if hasattr(agent.policy, 'initialize'):
agent.policy.initialize(self.game.actions[i])
def play(self):
action_indices = []
actions_chosen = []
for player_idx, agent in enumerate(self.agents):
actions = self.game.actions[player_idx]
action_idx, action = agent.act(actions)
action_indices.append(action_idx)
actions_chosen.append(action)
payoffs = self.game.payoff(action_indices)
return actions_chosen, payoffs
def expected_payoffs(self):
dists = [agent.policy(self.game.actions[i]) for i, agent in enumerate(self.agents)]
joint_dist = dists[0]
for dist in dists[1:]:
joint_dist = torch.einsum('i,j->ij', joint_dist.flatten(), dist).flatten()
payoffs_flat = self.game.payoffs.view(self.game.num_players, -1)
exp_payoffs = (joint_dist * payoffs_flat).sum(-1)
return exp_payoffsThe “play” function runs a round of the game. The “expected payoffs” returns the expected payoffs for each agent.
Example
Let’s look at an example. This first example is Stag Hunt.
if __name__ == "__main__":
staghunt_actions = [["Stag", "Hare"], ["Stag", "Hare"]]
p1_payoffs = [
[8, 0], # P1 plays Stag vs P2's [Stag, Hare]
[2, 3] # P1 plays Hare vs P2's [Stag, Hare]
]
p2_payoffs = [
[3, 1], # P2 plays Stag vs P1's [Stag, Hare]
[0, 2] # P2 plays Hare vs P1's [Stag, Hare]
]
payoffs = nn.Parameter(torch.tensor([p1_payoffs, p2_payoffs], dtype=torch.float))
stag_hunt = Game(payoffs, staghunt_actions, "Stag Hunt")
print(stag_hunt)
alice = Agent(
policy=lambda actions: torch.tensor([1.0 if a=="Stag" else 0.0 for a in actions]),
name="Alice"
)
bob = Agent(
policy=lambda actions: torch.ones(len(actions))/len(actions),
name="Bob"
)
stag_hunt_arena = Arena(stag_hunt, [alice, bob])
print(stag_hunt_arena.expected_payoffs())
print(stag_hunt_arena.play())
print(stag_hunt_arena.play())We initialize two deterministic agents, Alice and Bob. Alice always plays Stag. Bob plays are random. We then compute their expected payoffs (and play two rounds).
<Game "Stag Hunt" size=torch.Size([2, 2, 2]) learnable=True>
tensor([4., 2.], grad_fn=<SumBackward1>)
(['Stag', 'Hare'], tensor([0., 1.], grad_fn=<SelectBackward0>))
(['Stag', 'Stag'], tensor([8., 3.], grad_fn=<SelectBackward0>))We can see the expected payoff for Alice is 4 and the expected payoff for Bob is 2. In the two rounds they play, Bob first plays “Hare” (low payoffs for both players), then plays “Stag” (high payoffs).
Now let’s build differentiable agents:
...
diff_alice = Agent(
policy=LogitsPolicy(initialization='random'),
name="DiffAlice"
)
diff_bob = Agent(
policy=LogitsPolicy(initialization='random'),
name="DiffBob"
)
diff_agents = [diff_alice, diff_bob]
diff_stag_hunt_arena = Arena(stag_hunt, diff_agents)
optimizers = [
optim.Adam(diff_alice.policy.parameters(), lr=0.1),
optim.Adam(diff_bob.policy.parameters(), lr=0.1)
]
# Training loop
for step in range(200):
exp_payoffs = diff_stag_hunt_arena.expected_payoffs()
# Player 1 update
optimizers[0].zero_grad()
(-exp_payoffs[0]).backward(retain_graph=True)
optimizers[0].step()
# Player 2 update
optimizers[1].zero_grad()
(-exp_payoffs[1]).backward()
optimizers[1].step()
if step % 20 == 0:
print(f"Step {step}, Expected Payoffs: {exp_payoffs.detach().cpu().numpy()}")
# Final Policies
for i, agent in enumerate(diff_agents):
logits = agent.policy.logits.detach().numpy()
probs = agent.policy(stag_hunt.actions[i]).detach().numpy()
print(f"Agent {i+1} final logits: {logits}")
print(f"Agent {i+1} final probabilities: {probs}")
print(f"Agent {i+1} prefers: {'Stag' if probs[0] > probs[1] else 'Hare'}")
print()In the main loop, we optimize Alice and Bob’s policies separately via simultaneous updates (there are other choices, like alternative updates). We see:
Step 0, Expected Payoffs: [2.874151 1.4458582]
Step 20, Expected Payoffs: [7.565231 2.889052]
Step 40, Expected Payoffs: [7.9332013 2.9811559]
Step 60, Expected Payoffs: [7.9630227 2.9893801]
Step 80, Expected Payoffs: [7.972061 2.991976]
Step 100, Expected Payoffs: [7.9772897 2.9934921]
Step 120, Expected Payoffs: [7.9810405 2.994578 ]
Step 140, Expected Payoffs: [7.9839015 2.995403 ]
Step 160, Expected Payoffs: [7.986139 2.9960463]
Step 180, Expected Payoffs: [7.9879236 2.9965587]
Agent 1 final logits: [ 4.3300014 -2.8580525]
Agent 1 final probabilities: [9.9924505e-01 7.5498747e-04]
Agent 1 prefers: Stag
Agent 2 final logits: [ 3.8065035 -3.3711162]
Agent 2 final probabilities: [9.9923706e-01 7.6290034e-04]
Agent 2 prefers: Stagwhich is indeed the Nash equilibrium2.
Conclusion
Our differentiable agents successfully discovered that mutual cooperation (both playing Stag) is the Nash equilibrium in the Stag Hunt game. This approach can scale to continuous action spaces and handle n-player games, and this framework is also compositional (we can swap in different policy architectures, loss functions, or optimization algorithms to explore different solution concepts or learning dynamics)3.
Gradient descent doesn’t guarantee convergence to Nash equilibria in all games. Zero-sum games may cycle, games with multiple equilibria depend on initialization, and simultaneous updates can lead to instability.
